Detailed Pricing Guide for a 2500kVA Transformer Station Project

Comprehensive Guide to Constructing a 2500KVA Transformer Station in Vietnam

Constructing a transformer station in Vietnam involves meticulous planning, execution, and compliance with technical and legal standards. A 2500KVA – 22/0.4kV transformer station, in particular, serves not just an operational need but significantly contributes to the infrastructural stability of the region. QuangAnhcons, a seasoned contractor in the field, takes the lead on these projects, ensuring high-quality construction and reliable service. In this article, we provide a complete breakdown of the construction costs, detailed materials used, and the overall process, highlighting the expertise and capabilities of QuangAnhcons.

1.Construction Cost Overview

Detailed Cost Breakdown and Material Specifications

a. 22KV Transmission Line

• Materials:
  • 14m High-Voltage Transmission Line Poles, Iron Crossarms with specifications L2200x75x75x8mm/Zn, and additional components ensuring robust structural integrity.
  • Advanced electrical components such as 24Kv Standoff Insulators, Polymer Suspension Insulators, and high-grade covered cables.
  • A state-of-the-art “Recloser 3P 27kV 630A” to maintain circuit continuity and reliability with FDX control panels.

b. 2500KVA Substation – 22/0.4KV

• Substation Setup:
  • Core infrastructure includes high-voltage poles and composite crossarms enhanced with modern insulation materials.
  • Essential electrical components like the 3 PHASE MBA 2500KVA transformer, LBFCO 200A-24kV bases, and LA 18KV 10KA units.
  • Modern control systems housed within MSB Cabinets featuring ACB 3P 4000A and a comprehensive reactive power compensation system.

c. Additional Costs

• Project Management and Compliance:
  • This includes design and assessment costs, supervision, and fees associated with power cut connections and commissioning tests.
  • Documentation costs for substation installation and completion, as well as transport and handling of construction machinery and materials.

d. Total Investment Overview

2. Project Implementation and Warranty

Timeline:

• The entire project, from ground-breaking to operational handover, is meticulously planned to span a definitive timeline, ensuring that all phases, from laying the foundational poles to the final testing and commissioning, are completed efficiently within the scheduled time frames.

3. Warranty and After-Sales Service:

• QuangAnhcons offers a robust 12-month warranty for the transformer station, underscoring their commitment to quality and customer satisfaction. The warranty covers all components and labor, with an efficient service team ready to address and rectify any issues swiftly.

The construction of a 2500KVA – 22/0.4kV transformer station with QuangAnhcons is an investment in quality and reliability. With transparent pricing, detailed project outlines, and professional execution, QuangAnhcons ensures that each project contributes to the socio-economic development of the area, while providing stable and secure power solutions. For detailed quotations or to discuss your next project, contact QuangAnhcons directly at (+84) 9 1975 8191.

4.Dynamics Between Investor and Contractor in Building Projects

In the highlighted building project, the contractor holds the key role of managing all vital processes that determine the project’s outcome. The investor supports this role by providing the contractor with crucial legal papers, including up-to-date and notarized versions of land ownership documents, business permits, the representative’s identification, and environmental pacts. The contractor is tasked with maintaining up-to-date standards in electrical setups, establishing connections to the electrical grid, and managing the day-to-day operations until the project is fully completed. The project’s timeline is structured into an initial preparation period of 45 days

5.Payment Structure

Three-Stage Payment Plan for Transformer Station Construction

The payment schedule for building the transformer station is thoughtfully organized into three distinct phases. The initial phase kicks off with a payment immediately after the contractual agreement is in place, facilitating the contractor in initiating the transport and installation of necessary materials and equipment. The second stage of payment is prompted by the investor’s receipt notice of the transformer at the construction site, which subsequently allows for the transformer’s final installation and pre-commissioning activities. The concluding payment marks the completion of the energization and detailed testing procedures, jointly overseen by both the investor and the contractor, signifying the project’s fulfillment.

6.Dedication to Excellence and Customer Fulfillment

At the core of our business lies a steadfast dedication to delivering high-quality services at competitive prices, with specialized knowledge in constructing transformer stations. This commitment guarantees our clients’ complete satisfaction. Our support team is accessible around the clock, ready to offer any assistance or information needed. For personalized advice and tailored quotations for your 2500kVA 22/0.4kV transformer station requirements, please contact us. Our skilled team is prepared to assist with project planning, cost estimation, and navigating legal requirements to ensure a seamless construction experience.

7.Personalized Service Experience Invitation

Choosing Quang Anh CE Co., LTD for your 2500kVA – 22/0.4KV substation project offers more than typical construction services; it signifies a profound dedication to enhancing energy efficiency and system reliability, positively impacting the economic environment. We provide transparent pricing, superior service, and unparalleled expertise in the field, ensuring that your project with us establishes new standards in the electrical industry.

Quang Anh CE Co.,LTD

Contact Number: (+84) 9 1975 8191

Email Address: project@quanganhcons.com

Office Location:Unit 02, 08th floor, Pearl Plaza Building, 561A Dien Bien Phu Street, Ward 25, Binh Thanh District, Ho Chi Minh City

Operational Hours: Monday to Friday, from 8:00 am to 5:00 pm.

Please Note: All provided figures are estimations and may vary based on site conditions and market variables. Our direct communication channels are open for real-time updates and custom solutions.
